Key Features
-
Ultra-High Resolution – With a pixel pitch of 2.6mm, the screen provides sharp, crystal-clear visuals suitable for close-up viewing.
-
Lightweight & Portable – Modular cabinet design with easy-locking mechanisms ensures fast assembly and disassembly.
-
Seamless Display – Advanced panel alignment technology eliminates visible gaps for a smooth viewing experience.
-
Vivid Color & Brightness – High refresh rate and wide color gamut ensure lifelike colors and smooth motion.
-
Durable Build – Sturdy die-cast aluminum cabinet for long-lasting performance and easy transport.
-
Flexible Installation – Supports hanging or ground stacking for versatile event setups.
-
Energy Efficient – Low power consumption while delivering high brightness.
| Pixel Pitch | 2.604mm |
| LED Type | SMD 1515 Black |
| Max Brightness | 1500 nits |
| Panel Dimension | 500mm x 500mm x 73mm 19.7” x 19.7” x 2.87” |
| Panel Resolution (H x V) | 192 x 192 |
| Weight Per Panel | 8 kg | 17.64 lbs |
| Power Consumption Max/Average | 140W / 70W |
| BTU Max/Average | 480 / 220 |
| Transparency | Solid |
| Serviceability | Front / Rear |
| Curving (Concave & Convex) | Concave 5° ~ Convex 5° |
| Viewing Angle Vertical | 140° |
| Viewing Angle Horizontal | 140° |
| Refresh Rate | 7680 Hz |
| Gray Scale | 15 bit |
| Scan Ratio | 1/16 |
| Operational Temperature/Humidity | -20°C ~ 45°C, 10% ~ 90% RH -4°F ~ 113°F, 10% ~ 90% RH |
| Storage Temperature/Humidity | -40°C ~ 60°C, 10% ~ 90% RH -40°F ~ 140°F, 10% ~ 90% RH |
| IP Rating | IP40 |
| Certifications | CE, CB, ETL, FCC, UKCA, WEEE |
| Max. Hanging | 20 panels |
| Max. Stacking | 12 panels |
