Specifications
| Specification | Details |
|---|---|
| LED Type | SMD2020 |
| Pixel Pitch | 4.0 mm |
| Ingress Protection | IP31 (indoor only) |
| Viewing Distance | ≥ 4 m |
| Module Size | 256 × 128 mm |
| Module Pixel | 64 × 32 |
| Working Voltage | DC 5 V ±5% |
| Module Current | < 4 A |
| Module Consumption | < 20 W |
| Power Port | V/A |
| Data Port | HUB75E / SD801 |
| Module Maintenance | Front / Back |
| Brightness | 800–1000 nits |
| Refresh Rate | Up to 3840 Hz |
| Digital Processing | 14-bit |
| Gray Scale | 16,384 levels |
| Colours | ~687 Million |
| Color Temperature | 3200–9300 K Adjustable |
| Brightness Control | 0–100% Adjustable |
| Contrast Ratio | 4000:1 |
| Viewing Angle (H/V) | 140° / 140° |
| Operating Temp. | –15 °C ~ +50 °C |
| Operating Humidity | 10–85% RH |
| Lifespan | 100,000 hours |
| Installation Type | Wall-mounted |
| Control Mode | Video Sync |
